Wireless double track super high speed placement machine YDS-W600S
Smt Placement Machine 500k Cph Led Strip Light Making Smd Pick And Place Machine 3528 100m Led Strip Lighting Making Machine
Product description
Driven by a magnetic levitation motor,it is more silent,and the dual-track independent control can perfectly take materials twice on one machine and place it once,and the placement speed can reach 500,000 points per hour.
Features:
1.The placement head of the machine is a double-track double-suction rod, four-module structure, which can be controlled independently.
2.The whole body adopts precision welding, and the beam adopts high-strength cast iron structure.
3.The machine adopts linear motor ( magnetic levitation ) and imported servo motor drive, with high precision and high speed.
4.Low maintenance cost and simple operation.Operators can start production after simple training.
5.The machine adopts double electric feeder for feeding.
Product specification
| Mounting speed | 500000 CPH |
| Accuracy | ±0.04mm Chip |
| Minimum spacing | 7mm(Post together) |
| Circuit board | 240MM-260MM |
| Placement components range | LED chip 2121/3014/3020/2835/3528/5050/5730
And chip resistance 0603/0805/1206, IC, chip terminal, rectifier bridge stack, etc |
| Length×Width×Height | 3450×2350×1450mm |
| Total weight | 2500kg |
| placement mode | Pick-up and placement |
| Vision system | 10sets of imported Video cameras
Vision alignment,MARK correction |
| Circuit board | Thickness:0.1-0.8mm
Pressure Pneumatic |
| Operating system | Software: XP
Monitor: LED monitor
Inputting device: keyboard,mouse |
| Height | 15mm |
| Components | 2mm |
| Placed feeder Quantty | 90-120PCS(May increase according to the actual situation) |
| Power supply | Three phases AC 380V 50Hz |
| Power consumption | 10kw*2 |
| Pressure | 0.5mpa |
| Temperature | 25℃±5℃ |
| Rail Drive | The maximum length:1000mm |
| Transmission speed | >300mm/(S) |
| Transmission direction | Unidirectional front back |
| Transmission mode | Online |
| Bit mode | Optics |
| Air pressure | >5.0KG/CM2 |
| Air consumption | <100L/min*2 |
| Electrical control | Independent research and development |
| 1 set of movement control card mode | Independent research and development |
| XY axis drive mode | Servo motor,linear motor |
Applications:
Wireless placement machine is mainly used for the production of LED strip lights, tubes and panel lights.
These devices efficiently attach LED beads to substrates for a variety of lighting applications
